2^nd hand machines

We are offering the below listed 2^nd hand machines. If your are interested please contact our sales dept. so that we can tell you more details and can discuss with you possible adaptations to your application.

Automatic turret winder "Ecomat"

Manufacturer: Kampf

• Longitudinal slitting device with actual two scissors cutting knives (upgradable)
• Four edge trim winders with expansion chucking heads
• Dancer roll unit for the pull roll drive
• S-wrapped pull roll drive with additional nip roll
• Contact roll unit (for gap winding and contact winding mode)
• Rewinder with automatic reel change system (transfer onto unprepared cores)
• Rewinder with pneumatically operated chucks

• Roller body width:    1800 mm
• Material width:          max. 1600 mm (edge trimmed)
• Material thickness:  50 – 800 µm (from soft to rigid materials)
• Core diameter:        168 – 280 mm          changeable
• Reel diameter:          max. 1000 mm
• Core length:              800 – 1850 mm      changeable
• Speed:                        max. 50 m/min        changeable
• Tension:                    800 N                        changeable
• Operator side:          Right hand side (seen in web flow direction)
• Painting:                    RAL 9010 (pure white)

Photos
