Turret Unwinders

SOMATEC Turret Unwinders are used for continuous feeding of products to any converting or finishing process. Of course the splicing process is done automatically and safely at full production speed.

Depending on the individual situation either the economic Turret Unwinders UW - E and UW -C or the versatile Turret Unwinder UW - S can be used.



Preview turret unwinder UW 1200 E

Automatic Turret Unwinders UW - E and UW - C

with indexing disks


Technical Data's
  • Roll diameter: max. 1.200 mm (47")
  • Roll weight: max. 1.500 kgs (3300 lbs)
  • Material width: max. 2.000 mm (79")
  • Speed: max. 500 m/min (1600 ftm)
  • Other dimensions are available on request
Preview turret unwinder UW 1500 S

Automatic Turret Unwinder UW - S

with movable roll support arms
Technical Data's
  • Roll Diameter: max. 1.500 mm (60")
  • Roll weight: max. 3.500 kgs (7700 lbs)
  • Material width: max. 2.500 mm (98")
  • Speed: max. 600 m/min (2000 fpm)
  • Other dimensions are available on request

Machine brochure for downloading


Brochure Turret Unwinders UW
Automatic Turret Unwinders UW
PDF (3858 KB)
