Surface Winders


The SOMATEC Surface Winders offers a compact and low-cost alternative compared with turret winders or double station winders with accumulator. The surface winders are equipped with an automatic reel change system and can be equipped optionally with integrated slitting devices and handling devices. The main range of application is behind nonwoven production lines, within paper finishing lines and also in film production lines.

Depending on the individual task SOMATEC differentiates between three types of surface winders:

  • the economy priced Surface Winder SW - E for winding of nonwovens behind production lines
  • the versatile Surface Winder SW - S for ambitious in-line winding and slitting with additional support roll
  • the Reelwinder SW - R for winding of reels with biggest diameters




Automatic Surface Winder SW-E


Technical data's
  • Reel diameter: max. 1500 mm (59")
  • Reel weight: max. 1000 kg (2200 lbs)
  • Material width: max. 2000 mm (79")
  • Speed: max. 200 m/min (650 fpm)
  • Other data's are available on request

Automatic Surface Winder SW-S

Technical data's
  • Reel diameter: max. 1800 mm (71")
  • Reel weight: max. 1500 kg (3300 lbs)
  • Material width: max. 3000 mm (118")
  • Speed: max. 200 m/min (650 fpm)
  • Other data's are available on request

Automatic Surface Winder SW-R


Technical data's
  • Reel diameter: max. 3000 mm (118")
  • Reel weight: max. 3000 kg (6600 lbs)
  • Material width: max. 3000 mm (118")
  • Speed: max. 500 m/min (1640 fpm)
  • Other data's are available on request

Machine brochure for downloading


Brochure Surface Winders SW
Automatic Surface Winders SW
PDF (797 KB)
